Canon NP6412, 6412F Parts Manual.


After purchasing a new item, sometimes the product manuals can get caught up in the packaging and discarded or over time can get mislaid. Most of us think, I would never open up the product to find out what is wrong, so what do I really need my manual for? The assumption that your product manual is only for people with great technical skill is a misconception. Purchasing a parts manual for your copier can save time, money and aggravation.

The parts manual provides exploded diagrams with references to part numbers.
Contains 78 pages in pdf format of all the information you require to maintain your photocopier.
Print off one page or the whole manual.

Contents:-

ASSEMBLY LOCATION DIAGRAM
EXTERNAL COVERS, PANELS, ETC.
UPPER MAIN BODY
LOWER MAIN BODY
CONTROL PANEL ASSEMBLY
COPYBOARD COVER ASSEMBLY (NP6412)
ADF ASSEMBLY (NP6412F)
ADF TRAY ASSEMBLY (NP6412F)
SCANNER DRIVE ASSEMBLY
MAIN DRIVE ASSEMBLY
DELIVERY DRIVE ASSEMBLY
PAPER PICK-UP DRIVE ASSEMBLY
ADF DRIVE ASSEMBLY (NP6412F)
CASSETTE
PAPER PICK-UP ROLLER ASSEMBLY (CASSETTE)
ADF DELIVERY ASSEMBLY (NP6412F)
MIRROR ASSEMBLY 1
MIRROR ASSEMBLY 2
ZOOM MIRROR ASSEMBLY
BLANK EXPOSURE LAMP ASSEMBLY
TRANSFER ASSEMBLY
DEVELOPING ASSEMBLY
FIXING ASSEMBLY
FIXING FILM REPLACEMENT KIT
DC POWER SUPPLY PCB ASSEMBLY
CONTROL PANEL PCB ASSEMBLY
DC CONTROLER PCB ASSEMBLY
ADF CONTROLLER PCB ASSEMBLY (NP6412F)
NOISE FILTER PCB ASSEMBLY

---
